Features
HD CATV STB (Supports J.83 Annex B)
CA: Various Conditional Access supported
Supports H.264, MPEG2/4 video decoding
Supports MPEG-1, MPEG-2, AAC/HE-AAC(optional), DD/DD+ audio decoding
Specifications
System Configuration
| CPU | MIPS 74K application CPU 2k DMIPS, L2 256KByte |
| Flash | 128MB NAND Flash |
| RAM | 256MB DDR3 |
Connectivity
| RF IN | 1 x F-Type Female for CATV input |
| AV Output | 1 x 3.5mm Phone Jack (for CVBS, Audio L/R) |
| Ethernet | 1 x RJ45 |
| HDM | 1 x HDMI 1.4a |
| USB | 1 x USB2.0 Type-A |
| DC input | 1 x DC Jack |
Front IO
| LED | 1 x LED |
| IR receiver | 1 x IR sensor |
| Button | 3 x Button |
External power Adaptor
| AC input | 100~240V AC, 50/60Hz |
| DC Output | 12V DC, 1.25A |
